COL V140B Collator

Description

The Millitec Food Systems Ltd V140 Collator is a free standing conveyor assembly designed to feed product in to the production process in a controlled manner. The Collator is automatically controlled and requires minimal operator intervention.

EASY OPERATION
Timing, quantity, speed, and spacing can be fully controlled by the touchscreen. The input conveyors hold a buffer of product to eliminate wasteful gaps on the production line.
INTEGRABLE
The machine may be a standalone unit or integrated into an automated production line, compatible with other handling systems.

Other key features

Hygienic
It has been designed to be simple to dismantle and clean.
Optional Butterer Unit
We provide an option with an integral butterer unit.
Efficient

MAX Feed Rate: 60 Slices/min in one lane (120 Slices/min in total)

Specification

DIMENSIONS

  • Belt Height: 900 mm
  • Overall Length: 1800 mm
  • Overall Height: 1200 mm
  • Overall Width: 650 mm
  • Complete Unit Weight: 60 kg

PRODUCT SIZE

  • MAX Height: 40 mm
  • MAX Width: 130 mm
